EMI-5000 CLICK Test System
Measure click interference emitted from EUT power ports under operating conditions
Typical application scenarios
Intermittent interference is generated at EUT startup/shutdown of home appliances, power tools, electric medical devices, electric toys, vending machines, projectors and similar equipment due to relay switching or program control, with higher amplitude than continuous interference. It is categorized into clicks and non-clicks.A click refers to interference exceeding the quasi-peak limit of continuous disturbance, with duration ≤200ms, interval ≥200ms and no more than 2 occurrences within 2 seconds.The EMI-5000 CLICK Test System is widely used for intermittent click tests of electronic products including home appliances, power tools, electric medical devices and electric toys.
Main characteristics
1.Compliant with standards including CISPR 14-1 and CISPR 16-1-1.
2.PC-based platform with Windows 7 for user-friendly operation.
3.Built-in pulse generator supports self-calibration.
4.Real-time display and storage of all test data, graphs and tables.
5.Test configuration: click analyzer, LISN and dedicated click test software.
Technical Specifications
| Model | EMI-5000 |
| Test Frequencies | 150kHz、 500kHz、 1.4MHz、30MHz |
| Detector | Peak, Quasi-Peak (QP) |
| Display Parameters | Quasi-Peak level, Peak level, Click count (Short, Long), Non-click count, Test duration, Switching cycles, etc. |
| EUT Capacity | AC 250V,DC 250V,16A/32A (Higher capacities available upon customization) |
| Test Environment | Electromagnetic shielded enclosure |
