HVP-2 High Voltage Pulse Generator
It is a test instrument for evaluating the shock resistance of electronic products, complying with GB/T 17627.1, GB/T 17627.2 and GB/T 16927.1 standards
Typical application scenarios
HVP-2 High Voltage Pulse Generator is used for insulation performance tests of electricity meters, low-voltage electrical appliances, household appliances, components, sockets, connectors and cables. Designed in accordance with relevant domestic and international standards, it provides a reference criterion for evaluating the insulation performance of electrical and electronic equipment.
Main characteristics
1.Programmable voltage boosting, surge voltage up to 15 kV to satisfy severe test requirements.
2.Built-in differential voltage and current probes enable measurement of surge voltage and current peaks.
3.Supports threshold parameter setting function.
4.Built-in file system with USB flash drive read/write access for convenient import, export and storage of test programs and reports.
5.Adopts 10.1-inch LCD touch screen with friendly human-machine interface.
6.Equipped with RJ45 communication interface.
Technical Specifications
| Model | HVP-2 |
| Max. Output Voltage | 0.5kV~15kV±5% (Customizable to ± 3%) |
| Output Voltage Waveform | 1.2/50µs |
| Output Impedance | 500Ω, Tolerance ±20% |
| Output Polarity | Positive, Negative, or Automatic Alternating |
| Pulse Interval | 3s~9999s(Varies depending on voltage level) |
| Pulse Count | 1～9999（1s/step） |
| Trigger Mode | Manual, Automatic |
| Overcurrent Alarm | 0.3A~10A， Tolerance：±10%±3 digits |
