PF310A Digital Power Meter
High precision, full function, ultra-low standby power consumption
Typical application scenarios
PF310A is a multifunction, wide band, high accuracy digital power meter. It can measure DC, AC frequency range 0.5Hz-100kHz measurement. Besides, it can measure minimum 0.25μA current. It covers functions including harmonic analysis, integration, scaling, averaging, data/reviewing and communication, etc.
Suitable for scientific research universities, testing calibration, enterprise research and development, quality inspection and other high requirements occasions.
Main characteristics
1. The minimum measured current was 25 μA.
The minimum measurement current is as low as 25 μA, and the highest power measurement resolution is 1 µW, which is very suitable for standby power consumption testing and meets international standards (IEC62301, Energy Star, SPEC power).
2. The maximum test voltage is 1500V, and the direct test current is 50A
PF310A-H can realize 1500v/50A to directly measure the test occasions of large voltage and large current; it also has the current external input range of 2.5 mv ~ 10 v, making the test more convenient.
3. Integration measuring automatic range function
Integration is to accumulate the active power (W) or current (A) according to the time, to obtain the energy consumption (Wh) or power consumption (Ah), can obtain the power consumption of each operating state of household appliances. PF310A Not only can measure the positive and negative watt time, but also can measure the pere hour and DC current, can be used for battery charge and discharge energy, elevator lifting power consumption and storage measurement.
Usually in the integral mode, a fixed measurement range is required, and once the input voltage or current exceeds the maximum value of the selected range, the measurement will go wrong, and the increased measurement range needs to be retested. PF310A The range can be automatically and quickly switched in the integral mode, ensuring the accuracy and continuity of the measurement position.
4. Wide frequency measurement range
PF310A has a frequency measurement range of DC, from 0.5 to 100 kHz. Measure the distortion waveform such as square wave, pulse wave or special waveform containing DC components. Through the average active power measurement function, the distortion waveform can be accurately measured without any special mode setting, providing accurate power consumption data for the fluctuating power parts such as pulse wave, such as electric welding machine, HID power supply, etc.;
In the measurement of sine wave, such as the input waveform containing rich high frequency harmonic components, the measurement frequency range and bandwidth of the power meter are not enough, the high frequency harmonic component, PF310A can ensure that the accurate measurement of power and power factors when testing such products.
Technical Specifications
